RSA TWIN FIX LENGTH CUT with Cutting Polishing Washing Drying Stacking

RSA center for high-performance cutting, deburring, cleaning, drying and stacking for steel and stainless steel tubes.

Scope of Supply:

• 1 RSA high-speed precision saw model RASACUT NC 1500
• 1 Transfer system between the RASACUT precision saw and the RSA tube feeding system 1500
• 1 RSA tube feeding system 1500
• 1 RSA cleaning system RASACLEAN ET 1500

Including:

• 1 RSA drying system TURBODRY
• 1 RSA RASAPORT 1500 PR system

High production

High precision

Very short setup times

Easy handling

Easy machine connection

RSA High performance Saw RASACUT NC 1000: Fast and Precise

Round diameter: from 10 to 90 mm

Square diameter: from 10x10 to 65x65 mm

Wall thickness: from 1 to 5 mm

Bar weight: max. 5 Kg/m

Material: steel and stainless steel

Original lengths: 6,200 mm, optional 12,200 mm

Fixed length cutting and deburring: rounds from 150 to 1,000 mm (option from 100 to 2,000 mm)

Length/diameter ratio: 2:1

Length tolerance: +/- 0.5 mm
